| Article number | WG2191752 |
|---|---|
| External article number | 021 PI 00124 001 |
| Article status | Available |
| Number per pack | 1 |
|---|---|
| Minimum order quantity | 1 |
| Bolt Head Diameter [mm] | 26.0000 |
|---|---|
| Bolt Length [mm] | 60.0000 |
| Compression Height [mm] | 41.8000 |
| Length [mm] | 66.0000 |
| Recess Depth 1 [mm] | 12.9000 |
| Surface | Phosphated and graphite-coated |
| Cylinder Bore [mm] | 76.2500 |
| Supplementary Article/Supplementary Info 2 | with piston ring carrier with cooling duct |
| Component Number | 3. DSF 2,5 N 1. R2,0 IF CrK 2. M 2,0 IFU 2. M 2.0 IFU 1. R2.0 IF CrK 3. DSF 2.5 N |
| Recess Diameter [mm] | 49.0000 |
| Valve Pocket Depth 1 [mm] | 0.3000 |
| Valve Pocket Depth 2 [mm] | 0.4000 |
| Machined | with cut-out for oil jet |
| Article number | WG2191752 |
|---|---|
| Brand | Mahle |
| External article number | 021 PI 00124 001 |
| General information | |
| Article status | Available |
| Availability | |
| Minimum order quantity | 1 |
| EAN | 4057635176125 |
| Packaging length (cm) | 11,600 |
| Packaging width (cm) | 11,300 |
| Packaging height (cm) | 15,000 |
| Packaging weight (kg) | 0,510 |
