| Article number | WG1104583 |
|---|---|
| External article number | 061 38 00 |
| Article status | Available |
| Number per pack | 1 |
|---|---|
| Minimum order quantity | 1 |
| Bolt Head Diameter [mm] | 50.0000 |
|---|---|
| Bolt Length [mm] | 108.0000 |
| Piston Clearance [mm] | 0.1200 |
| Compression Height [mm] | 98.7600 |
| Length [mm] | 156.3000 |
| Recess Depth 1 [mm] | 24.5000 |
| Surface | Coated |
| Cylinder Bore [mm] | 127.0000 |
| Supplementary Article/Supplementary Info | with piston rings |
| Supplementary Article/Supplementary Info 2 | with piston ring carrier without cooling duct |
| Component Number | 3.DSF4,74 4,78 2. M2,38 5,3 IW 1.T3,5 5,3 IW C 1. T 3.5 IW Cr 2. M 2.38 IW 3. DSF 4.74 Cr |
| Recess Diameter [mm] | 75.1000 |
| Valve Pocket Depth 1 [mm] | 2.9600 |
| Machined | with cut-out for oil jet |
| Article number | WG1104583 |
|---|---|
| Brand | Mahle |
| External article number | 061 38 00 |
| General information | |
| Article status | Available |
| Availability | |
| Minimum order quantity | 1 |
| EAN | 4009026538500 |
| Packaging length (cm) | 16,100 |
| Packaging width (cm) | 16,100 |
| Packaging height (cm) | 22,800 |
| Packaging weight (kg) | 4,450 |
