| Article number | WG1094126 |
|---|---|
| External article number | 87-424000-00 |
| Article status | Available |
| Number per pack | 1 |
|---|---|
| Minimum order quantity | 1 |
| Bolt Head Diameter [mm] | 26.0000 |
|---|---|
| Bolt Length [mm] | 61.0000 |
| Piston Clearance [mm] | 0.0550 |
| Compression Height [mm] | 41.7000 |
| Length [mm] | 65.3000 |
| Recess Depth 1 [mm] | 13.2500 |
| Standard Size [STD] | 1 |
| Cylinder Bore [mm] | 75.0000 |
| Supplementary Article/Supplementary Info 2 | for keystone connecting rod with piston ring carrier with cooling duct |
| Component Number | 08-424000-00 |
| Recess Diameter [mm] | 41.8000 |
| Valve Pocket Depth 1 [mm] | 1.2000 |
| Machined | with cut-out for oil jet |
| Article number | WG1094126 |
|---|---|
| Brand | Nural |
| External article number | 87-424000-00 |
| General information | |
| Article status | Available |
| Availability | |
| Minimum order quantity | 1 |
| EAN | 4044197449514 |
| Packaging length (cm) | 9,600 |
| Packaging width (cm) | 9,600 |
| Packaging height (cm) | 8,500 |
| Packaging weight (kg) | 0,679 |
